神钢零件查询(F4GE9484D J601) - ENGINE - 5801370290 - 84301930.. (1/07-12/07) (3490.001) - FAN SUPPORT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 4899053 | [4] | SCREW,Hex Flg, M8 x 45 | TORHEXAGON BOLT |
| 3. | 4892426 | [1] | HUB | TORHUB |
| 4. | 4890732 | [1] | RETAINER,11.50mm ID x 52mm OD x 7mm | TORWASHER |
| 5. | 4892732 | [1] | BALL BEARING,34mm ID x 64mm OD x 37mm W | TORBALL BEARING |
| 6. | 2852172 | [1] | BOLT,Flng, M10 x 1.5 x 70mm | TORHEXAGON BOLT, M10X70 MM Superseded by part number: 16676834 |
| 7. | 32324 | [1] | SNAP RING,2.44", Int, #244 | GISPRING LOCKWASHER |
