纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (9.464[01]) - ADDITIONAL REAR COUNTERWEIGHT - OPTIONAL CODE 76073224 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
639 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79084381 | [1] | WEIGHT | LEC |
| 2. | 76045669 | [4] | STUD | LEC |
| 3. | 12164521 | [4] | NUT,Hex, M24, 2mm Pitch,19mm High, Cl 10 | MOD Superseded by part number: 12164527 |
| 4. | 79005245 | [10] | WASHER,25mm ID x 55mm OD x 9mm Thk | LEC24X55 |
| 5. | 15997737 | [2] | BOLT,Hex, M24 x 2 x 110mm, Cl 10.9 | BHB |
| 6. | 15998731 | [4] | BOLT,Hex, M24 x 2 x 180mm, Cl 10.9 | LEC Superseded by part number: 15998737 |
