神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.001.AB[01]) - CRANKCASE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
979 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2830081 | [1] | CYLINDER BLOCK,4 Cylinders | TORASSY, Incl 2 - 10 |
| 2. | 4899026 | [2] | DOWEL,M18 x 10 | TOR |
| 3. | 4895039 | [3] | EXPANSION PLUG,M17.73 | TOR |
| 4. | 4895038 | [4] | EXPANSION PLUG,M58.06 | TOR |
| 5. | 4895228 | [2] | EXPANSION PLUG,35.23mm x 7.94mm | TOR |
| 6. | 4891353 | [10] | SCREW,Flg Hd, M12 x 1.5 x 120 | TOR |
| 7. | 4895040 | [1] | BUSHING,54.39mm ID x 59.39mm OD x 25.4mm L | TOR |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 10. | 4895919 | [4] | BEARING ASSY,86.1mm D | TORASSY, Incl 2, 9 |
