纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (9.482[01]) - CUTTER BLADE (L=400MM) - LGP - OPTIONAL CODE 774188021 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76093764 | [1] | DOZER BLADE | LEC- ASSY |
| 2. | 8294273 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 2. | 79104464 | [1] | CUTTING EDGE | LEC- RIGHT IN ALTERNATIVE |
| 3. | 8294274 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 3. | 79104483 | [1] | CUTTING EDGE | LEC- LEFT IN ALTERNATIVE |
| 5. | 8282270 | [12] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 6. | 86015195 | [32] | NUT,M20 x 1.5, Cl 10 | RAC |
| 7. | 14497131 | [32] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 8. | 11118931 | [6] | BOLT,Hex, M16 x 50, 10.9 | WIN Superseded by part number: 412398 |
| 9. | 79005240 | [6] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC16X35X8 |
| 10. | 76047062 | [2] | CUTTING EDGE | LEC- CENTRAL |
| 11. | 8273211 | [20] | PLOW BOLT,Plow, M20 x 1.5 x 62mm, Cl 10.9 | LEC |
