神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.210.AF) - FUEL LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
793 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852549 | [1] | TUBE | TORASSY, Incl 4, 6, Fuel supply Superseded by part number: 504025707 |
| 2. | 2852108 | [1] | RIGID TUBE | TORASSY, Incl 4, 5, Fuel pump to filter Superseded by part number: 504046458 |
| 3. | 2852111 | [1] | CLIP | TOR Superseded by part number: 504065285 |
| 4. | 4894095 | [4] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CON |
