斗山零件查询INTAKE MANIFOLD DX380LC-3(OCEANIA) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
917 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
240203-00028A
|
[1] |
|
|
| 10. |
06.01923-3218
|
[4] |
BOLT ASS`Y M10X35
|
|
| 11. |
110436-00052A
|
[1] |
|
|
| 12. |
06.01913-3111
|
[2] |
BOLT ASS`Y M8X16
|
|
| 13. |
65.26803-7028B
|
[1] |
AIR HEATER
|
|
| 14. |
65.09904-0008
|
[2] |
GASKET;AIR HEATER
|
|
| 15. |
240401-00138
|
[1] |
|
|
| 16. |
06.01923-3126
|
[2] |
BOLT;HEX. M8X75
|
|
| 17. |
06.01923-3127
|
[2] |
|
|
| 18. |
110508-00848
|
[1] |
|
|
| 19. |
06.01913-2910
|
[2] |
. BOLT;HEX. M6X12
|
|
| 2. |
06.06225-0810
|
[4] |
BOLT;STUD M10X40
|
|
| 20. |
06.01923-3111
|
[1] |
BOLT, M8X16
|
|
| 3. |
06.16731-2108
|
[4] |
WASHER;SPRING
|
|
| 4. |
06.15010-2312
|
[4] |
WASHER;PLAIN
|
|
| 5. |
06.11063-8215
|
[4] |
NUT;HEX. M10
|
|
| 6. |
65.08902-0035
|
[2] |
GASKET;INTAKE MANIFOLD
|
|
| 7. |
06.01923-3218
|
[8] |
BOLT ASS`Y M10X35
|
|
| 8. |
240401-00098
|
[1] |
|
|
| 9. |
400618-00003
|
[1] |
|
|
