纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (9.651[04]) - ROPS CANOPY - ELECTRICAL SYSTEM - OPTIONAL CODE 784111221 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
726 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 76067653 | [2] | LEVER | LEC- STEERING |
| 3. | 76067647 | [2] | KNOB | LEC |
| 6. | 76067650 | [1] | SUPPORT | LEC |
| 7. | 76067645 | [1] | BEZEL | LEC- STEERING |
| 9. | 76067646 | [2] | SHIELD | LEC- LEVER |
| 10. | 76067654 | [1] | HOLDER | LEC- CONTROLS F/R |
| 11. | 76067236 | [2] | HANDLE | LEC |
| 12. | 76067638 | [1] | PLATE | LEC |
| 13. | 76067784 | [1] | GUARD | LEC |
| 14. | 76067640 | [1] | ARMREST | TOR Superseded by part number: 76067641 |
| 15. | 76067315 | [1] | GUIDE | LEC |
| 16. | 14303024 | [2] | HEX SOC SCREW,M4 x 12mm, Cl 8.8, Full Thd | TOR |
| 17. | 13307677 | [2] | SCREW,M3 x 10mm | LEC |
| 18. | 76301193 | [2] | BRUSH PIPE | LEC Superseded by part number: 76301497 |
