神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.254.AM) - MANIFOLD, SUCTION PIPE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
905 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852212 | [4] | FLANGE BOLT,Hex, M8 x 1.25 x 25mm | TOR |
| 1. | 4895294 | [4] | BOLT,Flng, M8 x 1.25 x 80mm, Cl 10.9 | TOR |
| 2. | 4895424 | [1] | INLET MANIFOLD | TOR |
| 3. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 3. | 2854866 | [2] | HEX SOCKET PLUG,3/4"-14 NPTF | TOR Superseded by part number: 4893036 |
| 4. | 4899921 | [2] | GASKET,1.2mm Thk | TORAir intake connection |
| 5. | 4899039 | [6] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TOR |
