| 1. |
86626591
|
[1] |
ROLL
|
PA
Backwrap, Steel
|
| 2. |
86590751
|
[2] |
BEARING ASSY,40mm ID
|
NH
Includes: Ref. 23 Superseded by part number: 87660576
|
| 3. |
9805640
|
[2] |
SHIELD,38.3mm ID x 74.5mm OD x 3.5mm Thk
|
NH
|
| 4. |
9848760
|
[1] |
BELT,127.00 mm W x 1140.00 mm L
|
NH
Standard
|
| 4. |
87385929
|
[1] |
RUBBER STRIP,1140mm L x 112mm W x 7.5mm Thk
|
PA
1140 x 89, Optional
|
| 5. |
86979982
|
[1] |
ANGLE
|
PA
|
| 6. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
|
| 7. |
9829395
|
[1] |
ROLLER
|
NH
Follower Superseded by part number: 84602063
|
| 8. |
86516311
|
[2] |
SUPPORT
|
NH
|
| 9. |
87030468
|
[2] |
HUB
|
PA
Superseded by part number: 87398962
|
| 10. |
9841725
|
[2] |
O-RING,0.21" Thk x 1.85" ID, -328, 40 Duro
|
NH
M47.00 ID x 5.3
|
| 11. |
811-12025
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M12 x 1.75 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 374895
|
| 12. |
844-8020
|
[8] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 13. |
614-10030
|
[2] |
BOLT,Hex, M10 x 1.5 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 43140
|
| 14. |
827-12045
|
[2] |
BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd
|
CAS
Superseded by part number: 86639031
|
| 15. |
844-12045
|
[4] |
BOLT,Hvy Hex, M12 x 45mm, Cl 8.8
|
CAS
Superseded by part number: 9804268
|
| 16. |
280519
|
[8] |
SELF-TAP SCREW,Hex, 5/16" - 12 x 1"
|
NH
|
| 17. |
614-10020
|
[2] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 43138
|
| 18. |
825-51412
|
[2] |
FLANGE NUT,M12, Flg Ser
|
CAS
Superseded by part number: 43436
|
| 19. |
322
|
[8] |
WASHER,8.73mm ID x 42.07mm OD x 3.43mm Thk
|
NH
Special
|
| 20. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 21. |
140046
|
[4] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 22. |
9848489
|
[2] |
BEARING ASSY,73 mm ID x 132.1976 mm OD x 38.10 mm, Round Bore
|
NH
Superseded by part number: 47531138
|
| 23. |
563733
|
[2] |
COLLAR
|
ZED
Lock
|
