神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.304.AS) - ENGINE OIL, DIPSTICK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
668 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 2. | 47434726 | [1] | ASSY, Incl 1, 7, 11, Dipstick oil | |
| 3. | 4895406 | [1] | EXPANSION PLUG,9.8mm OD | TOR |
| 4. | 4897330 | [1] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 5, 12 |
| 5. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 6. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 7. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
| 8. | 2852323 | [1] | SCREW,M8 x 1.25 x 14mm | TOR Superseded by part number: 16597925 |
| 8. | 2852134 | [1] | FLANGE BOLT,Hex, M12 x 1.75 x 25mm | TOR Superseded by part number: 16677735 |
| 9. | 2853427 | [1] | PROBE | TORGauge oil level Superseded by part number: 504025612 |
| 10. | 2853428 | [1] | BRACKET | TORClip, Oil fill pipe Superseded by part number: 504046336 |
| 12. | NSS | [1] | NOT SOLD SEPARAT | CON |
