神钢零件查询(F4GE9484D J619) - ENGINE - 5801584504 - YM02P00020P1 (11/12-) (10.400.BB[02]) - WATER PUMP, INLET MANIFOLD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
133 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852923 | [3] | SCREW | TORM10 x 1.5 x 90 Superseded by part number: 16593025 |
| 2. | 2854072 | [2] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 3. | 2852392 | [1] | SUPPORT | TORASSY, Incl 4 - 5 Superseded by part number: 500387647 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 5. | 4895576 | [2] | DOWEL | TOR |
| 6. | 2852922 | [1] | ELBOW | TOR Superseded by part number: 504042847 |
| 7. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY, Incl 8 - 9 |
| 8. | NSS | [2] | NOT SOLD SEPARAT | CON |
| 9. | 4895393 | [2] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 10. | 4895623 | [1] | HEX SOCKET PLUG,M16 x 1.5 | TORASSY, Incl 11 - 12, Inlet |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 12. | 4895625 | [1] | O-RING,13.3mm ID x 2.2mm Width | TOR Superseded by part number: 17281681 |
