沃尔沃零件查询D2-55; D2-55B; D2-55C; D2-55D; D2-55E; D2-55FElectrical SystemAlternatorEPC Volvo Penta Parts catalog
广数供应链运营团队, 14 02月, 2025，浏览：
554 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
872235
|
[1] |
Alternator
|
14V 60A
|
| 1. |
3803260
|
[1] |
Alternator, exch
|
14V 60A
|
| 1. |
|
|
|
|
| 2. |
|
|
|
|
| 3. |
3583617
|
[1] |
Screw
|
|
| 4. |
3583616
|
[1] |
Pulley
|
|
| 5. |
3583059
|
[1] |
Tensioner
|
|
| 6. |
945444
|
[1] |
Flange screw
|
|
| 7. |
947760
|
[1] |
Flange screw
|
|
| 8. |
976944
|
[1] |
Washer
|
|
| 9. |
948645
|
[1] |
Flange lock nut
|
|
| 10. |
978710
|
[1] |
V-belt
|
(967114)
|
| 11. |
21217571
|
[1] |
Housing
|
|
| 12. |
996063
|
[1] |
Flange screw
|
|
