纽荷兰零件查询(DC150.B) - CRAWLER DOZER TIER 2 (3/03-) (9.653[11]) - ROPS CAB - DOOR - OPTIONAL CODE 784110171 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
312 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76301168 | [2] | WIPER MOTOR | LEC24V |
| 2. | 76067148 | [2] | WIPER ARM | LEC |
| 3. | 76067149 | [2] | WIPER BLADE | LEC |
| 4. | 76067150 | [2] | LINKAGE | LEC |
| 5. | 76067151 | [2] | PIN | LEC |
| 6. | 76067146 | [6] | SPACER | LEC |
| 7. | 10902221 | [3] | BOLT,Hex, M6 x 16mm, CL 8.8 | BHB Superseded by part number: |
| 8. | 14496401 | [3] | WASHER,M6.4 x 12.00mm x 1.60mm | BHB Superseded by part number: 17094724 |
| 9. | 76301170 | [1] | WIPER MOTOR | LEC- RIGHT |
| 10. | 76301169 | [1] | BRACKET | LEC- LEFT |
| 11. | 16043431 | [1] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB8X1,25X16 Superseded by part number: 16605534 |
| 12. | 14496534 | [2] | WASHER,M8 | BUR Superseded by part number: 86624184 |
| 13. | 76067174 | [2] | SPACER | LEC |
| 14. | 76067175 | [2] | SEAL | LEC |
| 15. | 76067176 | [2] | PLATE | LEC |
| 16. | 76045509 | [4] | GROMMET | LEC |
| 17. | 16100814 | [2] | NUT,M8, Cl 8, DAC | LEC Superseded by part number: 16100811 |
| 18. | 14496501 | [2] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | TTF Superseded by part number: 86624184 |
