| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 00. | Y411995 | [1] | COMBUSTION CHAMBER | |
| 01. | Y412557 | [1] | PLATE | |
| 02. | J921630 | [16] | BOLT | |
| 03. | A590116 | [16] | WASHER;PLANE | |
| 06. | Y700913 | [1] | SIDE SHIELD (R) | |
| 07. | Y700914 | [1] | SIDE SHIELD (L) | |
| 10. | A590110 | [20] | WASHER;PLANE | |
| 11. | A590910 | [20] | WASHER;SPRING | |
| 12. | J901020 | [20] | BOLT |
