神钢零件查询(F4GE9484D J620) - ENGINE - 5801590401 - YM02P00016P1 (1/07-12/10) (10.304.AS) - ENGINE OIL, DIPSTICK Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
791 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852914 | [1] | BRACKET | TOR Superseded by part number: 504051850 |
| 2. | 2853429 | [1] | DIPSTICK | TORASSY, Incl 3 - 4 Superseded by part number: 504045917, 504045903 |
| 3. | 2853430 | [1] | RIGID TUBE | TOR Superseded by part number: 504045903 |
| 4. | 2853432 | [1] | DIPSTICK | TOR Superseded by part number: 504045917 |
| 5. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
| 6. | 4897330 | [1] | HEX SOCKET PLUG,M12 x 1.5 | TORASSY, Incl 7 - 8 |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONPlug, Incl in 6 |
| 8. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 9. | 2853428 | [1] | BRACKET | TOR Superseded by part number: 504046336 |
| 10. | 2853427 | [1] | PROBE | TOR Superseded by part number: 504025612 |
| 11. | 4895406 | [1] | EXPANSION PLUG,9.8mm OD | TOR |
| 12. | 2852323 | [1] | SCREW,M8 x 1.25 x 14mm | TOR Superseded by part number: 16597925 |
