神钢零件查询(F4GE9484D J620) - ENGINE - 5801590401 - YM02P00016P1 (1/07-12/10) (10.400.BC) - THERMOSTART Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
332 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899091 | [3] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 2853131 | [1] | HOUSING | TOR Superseded by part number: 504079269 |
| 3. | 2853445 | [1] | BRACKET | TOR Superseded by part number: 504079607 |
| 4. | 2853133 | [1] | GASKET,51.5mm ID x 61.5mm OD x 16.5mm Thk | TOR Superseded by part number: 504078856 |
| 7. | 84325989 | [1] | SEAL | TOR |
| 8. | NSS | [1] | NOT SOLD SEPARAT | CONThermostat, Incl in 5 |
