斗山零件查询OIL COOLER PIPING(3) DX380LC-3(OCEANIA) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
681 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-01392
|
[-] |
|
|
| 101. |
DS2023457
|
[1] |
|
|
| 18. |
124-00209D2
|
[1] |
CLIP
|
|
| 19. |
124-00208D8
|
[2] |
CLIP
|
|
| 25. |
2181-2627D1
|
[1] |
ADAPTER
|
|
| 30. |
DS2232172
|
[1] |
|
|
| 32. |
2181-2816D1
|
[1] |
ELBOW
|
|
| 33. |
2181-2816D4
|
[1] |
ELBOW
|
|
| 35. |
2181-2815D3
|
[1] |
ELBOW
|
|
| 36. |
DS2412031
|
[1] |
|
|
| 40. |
K1001029
|
[3] |
BOLT
|
|
| 5. |
DS20111454
|
[1] |
|
|
| 52. |
S8000181
|
[2] |
O-RING
|
|
| 53. |
S8000231
|
[2] |
O-RING
|
|
| 54. |
S8000381
|
[1] |
O-RING
|
|
| 56. |
S8030081
|
[3] |
O-RING
|
|
| 57. |
S8030121
|
[2] |
O-RING
|
|
| 58. |
S8030161
|
[2] |
O-RING
|
|
| 59. |
S8040121
|
[1] |
O-RING
|
|
| 60. |
110406-01481A
|
[1] |
|
|
| 62. |
DS0025033
|
[2] |
BOLT
|
|
| 7. |
2184-1197D26
|
[1] |
HOSE 1 3/16"-12UN-2B-1600L
|
|
