纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (5.652[28]) - ROPS CAB - SHROUD New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
350 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76067257 | [1] | CONVEYOR | LEC- INLET |
| 2. | 76067258 | [1] | CONVEYOR | LEC- LEFT DELIVERY |
| 3. | 76043575 | [2] | HOSE | LEC70 Superseded by part number: 76067828 |
| 4. | 76067742 | [5] | WASHER | LEC |
| 5. | 71404503 | [4] | HOSE CLAMP,69.6mm - 77mm | LEC60-80 |
| 6. | 76067259 | [1] | CONVEYOR | LEC- RIGHT DELIVERY |
| 7. | 16044024 | [3] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 8.8 | TTF |
| 8. | 16043924 | [7] | BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8, Full Thd | TTF |
| 10. | 16044124 | [2] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 8.8 | TTF |
| 11. | 76067302 | [2] | SEAL | TOR Superseded by part number: 76067806 |
| 12. | 76067705 | [4] | DIFFUSER | LEC |
| 13. | 76067745 | [5] | FLEXIBLE HOSE | LEC50 Superseded by part number: 76067833 |
| 14. | 13000790 | [10] | HOSE CLAMP,40mm - 60mm, Worm Gear | TTF Superseded by part number: 86050202 |
