| 2. |
249730
|
[15] |
SECURING STRAP
|
NH
1/8" x 8" Superseded by part number: 249730F, 249730F, 263117
|
| 3. |
86631455
|
[1] |
ANGLE
|
NH
|
| 4. |
9822519
|
[7] |
COMMUTATOR BRUSH
|
NH
|
| 5. |
9822520
|
[1] |
RESERVOIR, HYDRAULIC
|
NH
|
| 6. |
9847000
|
[1] |
HOSE,15.88mm ID x 374.65mm L
|
BAS
|
| 7. |
86977434
|
[1] |
U-BOLT,5/16" - 20 x 1.94" W x 2.50" L
|
PA
5/16"-18, 1-15/16" W x 2-1/2" L
|
| 8. |
86618630
|
[1] |
ANGLE
|
NH
|
| 9. |
86618552
|
[1] |
ANGLE
|
NH
|
| 10. |
87023511
|
[1] |
MOUNTING PARTS
|
NH
Tank
|
| 11. |
87040807
|
[1] |
PUMP
|
PA
Oiler
|
| 12. |
850420
|
[1] |
FLEXIBLE HOSE
|
NH
|
| 13. |
86618553
|
[1] |
ANGLE
|
NH
|
| 14. |
86643948
|
[1] |
BRACKET
|
NH
Superseded by part number: 87023512
|
| 15. |
625670
|
[1] |
GROMMET
|
NH
|
| 16. |
218-5103
|
[1] |
90 ELBOW,90 Degree Elbow, 7/16" - 20 Male JIC x 7/16" - 20 Male ORB
|
CAS
Includes: O-Ring, 1/4" Tube Superseded by part number: 216773
|
| 17. |
9848970
|
[1] |
PLASTIC-RUBBER TUBE,3.96mm OD x 10973mm L
|
PA
Lube, .156" OD x 10'
|
| 18. |
86521981
|
[2] |
REDUCER,5/32" Hose Barb x 5/32" Hose Barb
|
PA
|
| 20. |
844-6020
|
[4] |
BOLT,Hvy Hex, M6 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804256
|
| 22. |
844-12060
|
[1] |
BOLT,Hvy Hex, M12 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 9804270
|
| 23. |
86512420
|
[6] |
CARRIAGE BOLT,Rnd Head, M8 x 1.25 x 20mm, Full Thd, Cl 8.8
|
NH
|
| 25. |
825-2408
|
[6] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 26. |
9804279
|
[1] |
FLANGE NUT,Hex, M12, Cl 8
|
NH
Superseded by part number: 86512497
|
| 27. |
425-105
|
[2] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 28. |
832-46406
|
[4] |
NUT,M6 x 1, Cl 8
|
CAS
Superseded by part number: 353308
|
| 30. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 31. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 32. |
495-21031
|
[4] |
WASHER,1/4"
|
CAS
Superseded by part number: 80701, 72187262
|
| 33. |
515-2279
|
[2] |
CLAMP,5/16", Insul, 5/16" Bolt
|
CAS
Superseded by part number: 853764
|
