| 1. |
0C
|
[2] |
ORDER COMPONENTS
|
NH
Hydraulic Brake Axle & Hubs
|
| 2. |
87018701
|
[2] |
WHEEL
|
PA
16.00 x 17
|
| 3. |
86625632
|
[12] |
WHEEL NUT,Hex, M18 x 1.5
|
NH
Wheel, M18 x 1.5 UNF
|
| 8. |
87055651
|
[1] |
ARM ASSY.
|
PA
RH
|
| 9. |
86631645
|
[2] |
ACTUATOR
|
NH
|
| 10. |
235362
|
[1] |
CLEVIS PIN,19.05mm OD x 4mm L
|
NH
|
| 12. |
432-1240
|
[2] |
COTTER PIN,3/16" x 2 1/2"
|
CAS
Superseded by part number: 86523959
|
| 14. |
432-1224
|
[4] |
COTTER PIN,3/16" x 1-1/2"
|
CAS
Superseded by part number: 80754
|
| 15. |
378243
|
[2] |
WASHER,8.4mm ID x 21mm OD x 1.6mm Thk
|
NH
Superseded by part number: 63707, 63707, 86625263
|
| 16. |
832-46408
|
[5] |
NUT,M8 x 1.25, Cl 8
|
CAS
Superseded by part number: 86528579
|
| 17. |
87020056
|
[1] |
CABLE
|
PA
Brake
|
| 18. |
87020057
|
[1] |
CABLE,3720mm L
|
PA
Brake
|
| 19. |
87023508
|
[1] |
PLATE
|
PA
Connecting
|
| 20. |
87023507
|
[1] |
SPACER
|
PA
|
| 21. |
141979
|
[1] |
SPACER
|
PA
#10-24 x 1-15/16"
|
| 22. |
87032944
|
[1] |
PLATE
|
PA
|
| 24. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 26. |
844-8030
|
[2] |
BOLT,Hex, M8 x 1.25 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 87779272, 9804260
|
| 27. |
844-8025
|
[11] |
BOLT,Hvy Hex, M8 x 25mm, Cl 8.8
|
CAS
Superseded by part number: 9671714
|
| 28. |
825-2408
|
[8] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 29. |
84274758
|
[1] |
HAND BRAKE
|
ZED
|
| 30. |
87023506
|
[1] |
SUPPORT
|
PA
|
| 34. |
844-10030
|
[2] |
BOLT,Hvy Hex, M10 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9840672
|
| 35. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 41. |
263117
|
[1] |
CABLE TIE,292.1mm L, Nylon, Black
|
NH
CABLE STRAP
|
| 43. |
87055646
|
[1] |
ARM ASSY.
|
PA
LH
|
| 44. |
432-816
|
[2] |
COTTER PIN,1/8" x 1"
|
CAS
Superseded by part number: 80755
|
| 46. |
76877
|
[2] |
CLEVIS PIN,12.6mm OD x 34.52mm L
|
NH
|
| 48. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 49. |
86570141
|
[2] |
TYRE/TIRE
|
PA
19/45 - 17
|
| 50. |
86616183
|
[2] |
TIRE TUBE
|
PLO
Inner, 19/45 - 17
|
