神钢零件查询(F4GE9684B J600) - ENGINE 504116859 - 87050849 (1/07-) (0.12.0) - CAMSHAFT - TIMING CONTROL (2855736) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
400 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895323 | [6] | FLANGE BOLT,Hex, M8 x 1.25 x 40mm | LEC |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 4. | 4897457 | [1] | SUPPORT | TOR |
| 5. | 2855612 | [1] | CAMSHAFT | TOR- ASSY Superseded by part number: |
| 5. | 2855612R | [1] | REMAN-CAMSHAFT | RACF4GE9684B J600 ENGINE 504116859 - 87050849, ASSY Superseded by part number: 504094080R |
| 5. | 2855612C | [1] | Return Number | RACReturn Number |
| 6. | 4899080 | [1] | DOWEL,M6 x 8 L | TOR |
