神钢零件查询(F4GE9684B J600) - ENGINE 504116859 - 87050849 (1/07-) (0.27.0) - ENGINE OIL DIPSTICK (2856122 - 2856131) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
991 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | 4898502 | [1] | O-RING,0.364" ID x 0.504" OD x 0.07" | LEC Superseded by part number: 17277981 |
| 4. | 4895406 | [2] | EXPANSION PLUG,9.8mm OD | TOR |
| 5. | 4897330 | [2] | HEX SOCKET PLUG,M12 x 1.5 | TOR- Assy |
| 6. | 4895610 | [1] | O-RING,2.2mm Thk x 9.3mm ID | TOR |
| 7. | 2852134 | [1] | FLANGE BOLT,Hex, M12 x 1.75 x 25mm | TORM1X16mm Superseded by part number: 16677735 |
| 9. | 4895037 | [1] | EXPANSION PLUG,32.03mm | TOR |
| 11. | 4899020 | [2] | FLANGE BOLT,Hex, M8 x 1.25 x 20mm | TOR Superseded by part number: 16673635 |
| 12. | 2854075 | [1] | O-RING,0.103" Thk x 2.987" ID, -151 | TOR |
