| 1. |
87026750
|
[1] |
FRAME ASSY
|
PA
Main, North America, Includes: Decals
|
| 1. |
87026752
|
[1] |
FRAME ASSY
|
PA
Main, Europe & R.O.W., Includes: Decals
|
| 2. |
27639
|
[2] |
BUSHING,31.83mm ID x 38.19mm OD x 25.4mm L
|
NH
|
| 3. |
86643093
|
[2] |
INDICATOR
|
NH
|
| 4. |
86632214
|
[1] |
ARM
|
NH
Inner, Includes: Ref. 2 Superseded by part number: 87033334
|
| 5. |
87040530
|
[2] |
DISC
|
PA
|
| 6. |
NS
|
[2] |
NOT SERVICED
|
BAS
SPROCKET 13T, Plastic, Production Only {87050058}
|
| 6. |
66614
|
[2] |
SPROCKET,RC80, 13T
|
NH
13T, Steel, Service Only Superseded by part number: 84401598
|
| 7. |
144819C91
|
[2] |
BEARING
|
IH
Superseded by part number: 149261C91
|
| 8. |
86637291
|
[3] |
SPACER
|
NH
Plated
|
| 9. |
86610108
|
[1] |
SPROCKET
|
NH
25 T, RC 80 Superseded by part number: 87664055
|
| 10. |
86632217
|
[1] |
LIFT ARM
|
NH
Outer Superseded by part number: 87033674
|
| 11. |
86637258
|
[3] |
TUBE,19.05 mm OD x 228.60 mm L
|
NH
|
| 12. |
86618710
|
[3] |
SPRING,1-3/8" OD x 8-5/8" L
|
NH
Compression, 8-5/8" L
|
| 13. |
86637254
|
[3] |
ROD
|
NH
|
| 14. |
86610107
|
[1] |
SPROCKET
|
NH
Triple, (1)13T, (1)14T, (1)18T, RC 80 Superseded by part number: 87664056
|
| 15. |
86610110
|
[1] |
SPROCKET
|
NH
Double, (1)20T, (1)17T, RC 80 Superseded by part number: 87664057
|
| 16. |
86609558
|
[1] |
BEARING ASSY,45mm ID
|
NH
|
| 17. |
86629575
|
[1] |
SHAFT
|
NH
|
| 18. |
86611436
|
[1] |
ARM
|
NH
|
| 19. |
86549269
|
[1] |
CHAIN,RC80, 64 Links x 25.4mm = 1625.6mm
|
PA
Roller, RC 80, 64 Pitches, Includes: Ref. 52
|
| 20. |
86562829
|
[1] |
CHAIN,100, 67 Links x 31.75mm = 2127.25mm
|
NH
Roller, RC 100, 67 Pitches, Includes: Ref. 53 & 54
|
| 21. |
87021804
|
[1] |
CHAIN,Roller, 68 Links x 25.4mm = 1727.2mm
|
PA
Roller, RC 80, 68 Pitches, Includes: Ref. 52
|
| 23. |
140045
|
[4] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 24. |
140046
|
[13] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 25. |
814-12050
|
[1] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 9706702
|
| 26. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
Superseded by part number: 80710
|
| 27. |
825-1412
|
[17] |
NUT,M12, Cl 8
|
CAS
Superseded by part number: 9706685
|
| 29. |
9804273
|
[1] |
BOLT,Hex, M16 x 60mm, Cl 8.8
|
NH
|
| 30. |
432-1232
|
[2] |
COTTER PIN,3/16" OD x 2" L
|
CAS
Superseded by part number: 87400
|
| 31. |
335890
|
[2] |
CARRIAGE BOLT,Sq Nk, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
NH
|
| 32. |
844-12030
|
[2] |
BOLT,Hvy Hex, M12 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 9670066
|
| 33. |
80043480
|
[1] |
BOLT
|
PA
Rnd Hd Square Neck, M8.8 Course Thd
|
| 34. |
844-10020
|
[4] |
BOLT,Hvy Hex, M10 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86050286
|
| 35. |
844-12045
|
[4] |
BOLT,Hvy Hex, M12 x 45mm, Cl 8.8
|
CAS
Superseded by part number: 9804268
|
| 36. |
814-16060
|
[1] |
BOLT,Hex, M16 x 2 x 60mm, Cl 8.8
|
CAS
Superseded by part number: 323866
|
| 37. |
811-16060
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, M16 x 2 x 60mm, Cl 8.8
|
RAC
Superseded by part number: 87552612
|
| 38. |
328754
|
[1] |
CARRIAGE BOLT,M12 x 1.75 x 40mm, Cl 8.8
|
NH
|
| 39. |
694478
|
[1] |
WASHER,13.5mm ID x 57.15mm OD x 4.8mm Thk
|
NH
Hardened, 1/2"
|
| 40. |
58821
|
[1] |
WASHER,45.24mm ID x 56.36mm OD x 1.65mm Thk
|
NH
Special
|
| 41. |
86619043
|
[1] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
|
| 42. |
27696
|
[1] |
WASHER,1.281" ID x 2" OD x .060" Thk
|
NH
Special Superseded by part number: 675
|
| 43. |
142656
|
[1] |
WASHER,33.35mm ID x 47.63mm OD x 3.43mm Thk
|
NH
1-1/4"
|
| 44. |
495-21056
|
[12] |
WASHER,1/2"
|
CAS
Superseded by part number: 72187265, 80700
|
| 45. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
Superseded by part number: 87365
|
| 46. |
100-16175
|
[1] |
SNAP RING,#175, Ext
|
CAS
Superseded by part number: 86515809
|
| 47. |
412441
|
[1] |
ROLLER BEARING,40mm ID x 80mm OD x 21mm W, Round Bore
|
PA
& Collar
|
| 48. |
86620027
|
[2] |
FLANGED BEARING,80.02mm ID x 147.6mm OD x 4mm Thk
|
NH
Bearing
|
| 49. |
832-46416
|
[3] |
NUT,M16 x 2, Cl 8
|
CAS
Superseded by part number: 86000441
|
| 50. |
115680
|
[1] |
HOOK
|
NH
S
|
| 51. |
87017554
|
[1] |
DRIVEN SPROCKET
|
PA
Includes: Bearing 144819C91
|
| 52. |
9620569
|
[1] |
CONNECTING LINK,RC80, 1 Link x 25.4mm = 25.4mm L
|
NH
Superseded by part number: 241-1418
|
| 53. |
86977432
|
[1] |
LINK,31.75mm Pitch
|
NH
Offset
|
| 54. |
86595263
|
[1] |
LINK,31.75mm Pitch
|
PA
|
| 55. |
26306
|
[2] |
DRIVE BUSHING,25.47mm ID x 31.82mm OD x 31.8mm L
|
NH
|
| 56. |
87037410
|
[4] |
HINGE
|
PA
Lower, Square-Shaped
|
| 57. |
308761
|
[8] |
CARRIAGE BOLT,M8 x 1.25 x 25mm, Cl 8.8
|
NH
|
| 58. |
322358
|
[8] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 59. |
825-2408
|
[8] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 60. |
86631518
|
[2] |
DANGER DECAL
|
NH
English
|
| 60. |
86632801
|
[2] |
DECAL
|
NH
DANGER, French
|
