纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (0.550[01]) - ENGINE COOLING SYSTEM New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
803 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76053580 | [1] | RADIATOR | LECTESIO ASSY - SEE TAV.4 |
| 2. | 76069598 | [1] | BRACKET | LEC |
| 3. | 76053630 | [1] | CONVEYOR | TOR- ASSY |
| 4. | 76053626 | [1] | RADIATOR GRILLE | LEC- RIGHT |
| 5. | 76053625 | [1] | RADIATOR GRILLE | LEC- LEFT |
| 6. | 16100821 | [2] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 7. | 16043831 | [2] | SCREW,Hex, M8 x 1.25 x 30mm, Cl 10.9, Full Thd | BHB Superseded by part number: |
| 10. | 4977098 | [2] | ISOLATOR | LEC |
| 11. | 4977099 | [1] | WASHER | LEC Superseded by part number: 75223895 |
| 12. | 4977100 | [1] | SPACER | LEC Superseded by part number: 75223896 |
| 13. | 11113631 | [1] | SCREW,Hex, M12 x 70mm, Cl 10.9 | LEC Superseded by part number: 86505259 |
| 14. | 12648531 | [3] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 15. | 12577521 | [1] | NUT,M12 x 1.75 | LEC |
| 16. | 11112431 | [2] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 17. | 79110359 | [2] | WASHER | LEC |
| 18. | 11114031 | [2] | BOLT,Hex, M12 x 90, 10.9 | LEC Superseded by part number: 412605 |
| 19. | 16043431 | [12] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 20. | 14496531 | [10] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
| 21. | 76046348 | [2] | SEAL | TOR |
| 22. | 4974337 | [4] | PAD | LEC Superseded by part number: 76069292 |
| 23. | 4974344 | [2] | SPACER | LEC |
| 24. | 4974343 | [4] | WASHER | LEC Superseded by part number: 79111680 |
