| 1. |
86836619
|
[1] |
RAKE
|
PA
Superseded by part number: 87023404
|
| 2. |
86635405
|
[1] |
ROLL
|
NH
Starter
|
| 3. |
9822519
|
[1] |
COMMUTATOR BRUSH
|
NH
|
| 4. |
86643948
|
[1] |
BRACKET
|
NH
Superseded by part number: 87023512
|
| 5. |
PL
|
[1] |
PROCURE LOCALLY
|
BAS
Tube, Nylon, 8'
|
| 6. |
87042326
|
[1] |
HOLDER
|
PA
|
| 7. |
249730
|
[1] |
SECURING STRAP
|
NH
1/8" x 8" Superseded by part number: 249730F, 249730F, 263117
|
| 8. |
675162
|
[1] |
WIRE CLAMP,6.3mm, Coat, 10.3mm Bolt Hole, P Type
|
NH
|
| 9. |
711-10030
|
[2] |
CARRIAGE BOLT,Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 10. |
140045
|
[5] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 11. |
825-2410
|
[4] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 12. |
844-10020
|
[1] |
BOLT,Hvy Hex, M10 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86050286
|
| 13. |
86610638
|
[2] |
BEARING ASSY,45mm ID
|
NH
|
| 15. |
811-10040
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 374892
|
| 16. |
515-2195
|
[1] |
CLAMP,3/8", Insul, 1/4" Bolt
|
CAS
Superseded by part number: 86050346
|
| 17. |
275-5478
|
[1] |
SELF-TAP SCREW,Hex Hd, 1/4" x 1/2"
|
CAS
Superseded by part number: 87667
|
| 18. |
122889
|
[4] |
SHIM
|
NH
.015" Superseded by part number: 87658033
|
| 19. |
86619043
|
[1] |
WASHER,45.2mm ID x 60.3mm OD x 3.68mm Thk
|
NH
|
