纽荷兰零件查询(DC150LT) - CRAWLER DOZER (6/00-) (2.348[01]) - TRACK GUARDS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
222 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76053971 | [2] | GUARD | LEC- LOWER RIGHT ASSY |
| 1. | 76053969 | [2] | GUARD | LEC- LOWER LEFT ASSY |
| 3. | 76053960 | [4] | GUARD | LEC- LOWER ASSY |
| 4. | 76053970 | [4] | PLATE | LEC- REAR Superseded by part number: 76093933 |
| 5. | 76054687 | [1] | GUARD | TOR- UPPER REAR LEFT |
| 5. | 76054688 | [1] | GUARD | TOR- UPPER REAR RIGHT |
| 7. | 76054689 | [2] | GUARD | LEC- UPPER - FRONT |
| 11. | 11390531 | [24] | BOLT,Hex, M16 x 1.5 x 40, 10.9, Full Thd | LEC Superseded by part number: 11390534 |
| 12. | 79005240 | [24] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC16X35,5X8 |
| 13. | 11112431 | [20] | SCREW,Hex, M12 x 30mm, Cl 10.9, Full Thd | LEC Superseded by part number: 87015736 |
| 14. | 12648531 | [30] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 15. | 12577521 | [8] | NUT,M12 x 1.75 | LEC |
| 16. | 11113231 | [8] | BOLT,Hex, M12 x 50mm, Cl 10.9 | BHB Superseded by part number: 337476 |
| 17. | 11113731 | [2] | SCREW,Hex, M12 x 75mm, Cl 10.9 | LEC |
| 18. | 76068232 | [2] | LID | LEC |
| 19. | 11106231 | [8] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9 | LEC |
| 20. | 14496631 | [8] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | LEC Superseded by part number: 14496621 |
