| 1. |
86637849
|
[1] |
SPACER
|
NH
|
| 2. |
86643382
|
[1] |
ARM
|
PA
|
| 3. |
647765
|
[1] |
SPACER
|
NH
Superseded by part number: 87022950
|
| 4. |
86610200
|
[3] |
THREADED INSERT,M8 x 1.25
|
NH
M8
|
| 5. |
86631648
|
[1] |
TRIP
|
NH
|
| 6. |
177822
|
[1] |
SPACER,8.33mm ID x 12.7mm OD x 4.32mm Thk
|
NH
|
| 7. |
86633143
|
[1] |
PIVOT ASSY.
|
PA
Superseded by part number: 87028757
|
| 8. |
86632684
|
[1] |
BAR
|
PA
Superseded by part number: 87035429
|
| 9. |
86525007
|
[1] |
SPACER
|
GI
Superseded by part number: 86634543
|
| 10. |
163826
|
[1] |
SPRING,Extension, 0.732” OD x 2.75” L
|
WIN
|
| 11. |
783681
|
[1] |
SWITCH
|
NH
Micro, SPDT, Roller Arm Actuator
|
| 12. |
86633755
|
[1] |
SUPPORT
|
PA
Superseded by part number: 87660217
|
| 14. |
86628305
|
[1] |
WARNING SIGN
|
NH
Bale Size
|
| 16. |
814-8035
|
[1] |
BOLT,Hex, M8 x 1.25 x 35mm, Cl 8.8
|
CAS
Superseded by part number: 412479
|
| 17. |
814-12070
|
[1] |
BOLT,Hex, M12 x 1.75 x 70mm, Cl 8.8
|
IH
Superseded by part number: 9706717
|
| 18. |
844-8020
|
[2] |
BOLT,Hvy Hex, M8 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 9804258
|
| 19. |
844-8040
|
[1] |
BOLT,Hvy Hex, M8 x 40mm, Cl 8.8
|
CAS
Superseded by part number: 86511842
|
| 20. |
434-58
|
[1] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1/2", Gr 5
|
CAS
Superseded by part number: 280616
|
| 22. |
88363
|
[2] |
SCREW,Fillister Hd, #6 - 32 x 1 1/4"
|
NH
|
| 23. |
811-10020
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86512422
|
| 24. |
64263
|
[1] |
WASHER,13.49mm ID x 31.8mm OD x 1.5mm Thk
|
NH
Special, .060"
|
| 25. |
249100
|
[1] |
WASHER,0.78" ID x 1.25" OD x 0.06" Thk
|
NH
Special
|
| 26. |
257314
|
[3] |
WASHER
|
NH
Special
|
| 27. |
86637848
|
[1] |
WASHER,13.5mm ID x 38.1mm OD x 3.68mm Thk
|
NH
1-1/2" OD, Plated
|
| 28. |
495-31016
|
[2] |
WASHER,#6
|
CAS
Superseded by part number: 86511189
|
| 29. |
322358
|
[4] |
BELLEVILLE WASHER,M8 Bolt Size x 18mm OD x 1.4mm Thk
|
NH
|
| 30. |
140046
|
[1] |
BELLEVILLE WASHER,M12 Bolt Size x 27mm OD x 1.8mm Thk
|
NH
|
| 31. |
140045
|
[2] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 33. |
80801
|
[1] |
WING NUT
|
NH
5/16"-18
|
| 34. |
193-1003
|
[2] |
NUT,Keps, w/LW,#6-32
|
CAS
Superseded by part number: 280859
|
| 35. |
825-2408
|
[2] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 36. |
825-2410
|
[2] |
FLANGE NUT,M10 x 1.5, Flg, Cl 8
|
CAS
Superseded by part number: 9804278, 87778057
|
| 38. |
432-816
|
[2] |
COTTER PIN,1/8" x 1"
|
CAS
Superseded by part number: 80755
|
| 39. |
195183
|
[2] |
BUSHING,19.13mm ID x 22.3mm OD x 12.7mm L
|
NH
|
| 40. |
87049742
|
[1] |
CHANNEL
|
PA
|
