神钢零件查询(F4GE9684B J604) - ENGINE - 504360953 - 84152355 (1/08-12/10) (0.31.5) - HEAT EXCHANGER - ENGINE (2853333) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
595 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899019 | [15] | SCREW,Hex Flg, M8 x 1.25 x 35 | TOR |
| 2. | 4899643 | [1] | FILTER HEAD | TORASSY |
| 3. | 2853781 | [1] | PLUG,Hex, M22 x 1.5 ORB | TORASSY Superseded by part number: 504096409 |
| 4. | 4896404 | [1] | PLUNGER,10mm ID, 12mm OD, 15.44mm ID, 18.26mm OD | TOR |
| 5. | 4895045 | [1] | SPRING,Compression, 14.7mm OD x 66mm L | TOR |
| 6. | 17916280 | [1] | SEAL | TOR |
| 7. | J936365 | [1] | VALVE PRESSURE RELIE | CAS Superseded by part number: 4896410 |
| 8. | 4893391 | [1] | ADAPTER,M24 x 2 x M27 x 2 | TOR |
| 9. | 2853604 | [1] | OIL COOLER | TOR |
| 9. | 4896407 | [1] | OIL COOLER | TOR Superseded by part number: |
| 10. | 2830559 | [1] | GASKET,0.5mm Thk | TOR |
| 11. | 4896409 | [1] | GASKET,1.55mm Thk | TOR |
