现代零件查询HBF20/25/30/32-7 CABIN 1(OPTION,NEW)EPC Hyundai
广数供应链运营团队, 14 02月, 2025，浏览：
851 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
71FH-50031
|
[1] |
CABIN ASSY
|
|
| . |
71FH-50031
|
[1] |
CABIN ASSY
|
|
| 1. |
71FH-51010
|
[1] |
HEADGUARD W.A
|
|
| 2. |
71FH-51021
|
[1] |
FR DOOR W.A-LH
|
|
| 3. |
71FH-51031
|
[1] |
FR DOOR W.A-RH
|
|
| 4. |
71FH-51041
|
[1] |
RR DOOR W.A-LH
|
|
| 5. |
71FH-51051
|
[1] |
RR DOOR W.A-RH
|
|
| 6. |
71FH-51061
|
[1] |
PLATE-FRONT
|
|
| 7. |
71FH-51070
|
[1] |
PLATE-REAR
|
|
| 8. |
71FH-51081
|
[1] |
PLATE-REAR DOOR
|
|
| 9. |
71FH-51091
|
[1] |
PLATE-TOP
|
|
| 11. |
71FH-51111
|
[1] |
SIDE PLATE-LH
|
|
| 12. |
71FH-51121
|
[1] |
SIDE PLATE-RH
|
|
| 13. |
71FH-51130
|
[1] |
COVER-REAR
|
|
| 25. |
71EH-13140
|
[2] |
HANDLE ASSY
|
|
| 26. |
72FA-12100
|
[3] |
DOOR LATCH-LH
|
|
| 27. |
72FA-12110
|
[2] |
DOOR LATCH-RH
|
|
| 28. |
71FE-51230
|
[5] |
STRIKER
|
|
| 29. |
S403-121002
|
[5] |
WASHER-PLAIN
|
|
| 30. |
71FH-51241
|
[4] |
BRACKET-LATCH
|
|
| 31. |
71FH-51250
|
[2] |
BRACKET-RH
|
|
| 33. |
S661-360400
|
[4] |
CAP-RUBBER
|
|
| 34. |
71FQ-51221
|
[2] |
PLATE
|
|
| 41. |
71FH-51260
|
[1] |
COVER
|
|
| 42. |
S771-022000
|
[2] |
WEATHER STRIP
|
|
| 43. |
S771-006000
|
[2] |
WEATHER STRIP
|
|
| 44. |
S771-011000
|
[2] |
WEATHER STRIP
|
|
| 45. |
S772-011000
|
[2] |
WEATHER STRIP
|
|
| 46. |
S772-016000
|
[2] |
WEATHER STRIP
|
|
| 47. |
S772-009000
|
[1] |
WEATHER STRIP
|
|
| 48. |
S771-033000
|
[1] |
WEATHER STRIP
|
|
| 49. |
71M6-51820
|
[1] |
GAS SPRING
|
|
| 53. |
S131-05124V
|
[69] |
SCREW-W/WASHER
|
|
| 54. |
S771-010500
|
[1] |
WEATHER STRIP
|
|
| 55. |
71FH-51281
|
[2] |
HINGE-LH
|
|
| 56. |
S035-05152V
|
[12] |
BOLT-W/WASHER
|
|
| 57. |
74L3-04450
|
[8] |
WASHER-COPPER
|
|
| 58. |
71FH-51290
|
[1] |
HEAD LINING
|
|
| 59. |
S035-082022
|
[10] |
BOLT-W/WASHER
|
|
| 62. |
S017-080652
|
[12] |
BOLT-HEX
|
|
| 63. |
S205-08100V
|
[12] |
NUT-HEX
|
|
| 64. |
S411-08000V
|
[12] |
WASHER-SPRING
|
|
| 65. |
S403-08200V
|
[24] |
WASHER-PLAIN
|
|
| 66. |
71FH-51320
|
[1] |
SIDE PLATE-LH
|
|
| 67. |
71FH-51330
|
[1] |
SIDE PLATE-RH
|
|
| 68. |
S771-005000
|
[2] |
WEATHER STRIP
|
|
| 70. |
71FH-51340
|
[1] |
BRACKET-LICENSE
|
|
