沃尔沃零件查询L40 Variable displacement motor 2TYPE 191, 192 SER NO - 10001910001-NoneNoneNoneNoneAutodata Volvo online
广数供应链运营团队, 14 02月, 2025，浏览：
538 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
ZM2810361
|
[1] |
Hydraulic motor
|
|
| 10. |
ZM2905685
|
[1] |
Gear
|
|
| 11. |
ZM2905686
|
[1] |
Axle
|
|
| 12. |
VOE14503878
|
[1] |
Ring
|
55x2
|
| 13. |
ZM2905692
|
[1] |
Washer
|
2,65 mm
|
| 13. |
ZM2905693
|
[REQ] |
Washer
|
2,70 mm
|
| 13. |
ZM2905694
|
[REQ] |
Washer
|
2,75 mm
|
| 13. |
ZM2905695
|
[REQ] |
Washer
|
2,80 mm
|
| 13. |
ZM2905696
|
[REQ] |
Washer
|
2,85 mm
|
| 13. |
ZM2905697
|
[REQ] |
Washer
|
2,90 mm
|
| 13. |
ZM2905698
|
[REQ] |
Washer
|
2,95 mm
|
| 2. |
VOE15058556
|
[1] |
Retaining ring
|
72x2,5
|
| 13. |
ZM2905699
|
[REQ] |
Washer
|
3,00 mm
|
| 14. |
ZM2903167
|
[1] |
Roller bearing
|
33111
|
| 15. |
ZM2905691
|
[1] |
Spacer washer
|
3,80 mm
|
| 15. |
ZM2905690
|
[REQ] |
Spacer washer
|
3,85 mm
|
| 15. |
ZM2905689
|
[REQ] |
Washer
|
3,90 mm
|
| 15. |
ZM2905688
|
[REQ] |
Spacer washer
|
3,95 mm
|
| 15. |
ZM2905687
|
[REQ] |
Spacer washer
|
4,00 mm
|
| 16. |
ZM2903166
|
[1] |
Roller bearing
|
|
| 17. |
ZM2903176
|
[1] |
Cylinder
|
|
| 18. |
ZM2903179
|
[1] |
Piston
|
|
| 3. |
VOE14211609
|
[1] |
Back-up ring
|
56x72
|
| 19. |
ZM2905709
|
[14] |
Seal
|
|
| 20. |
ZM2905701
|
[1] |
Pivot
|
|
| 21. |
ZM2905708
|
[1] |
Spring
|
|
| 22. |
ZM2905702
|
[1] |
Tuning plate
|
3,50 mm
|
| 22. |
ZM2905703
|
[REQ] |
Tuning plate
|
3,60 mm
|
| 22. |
ZM2905704
|
[REQ] |
Tuning plate
|
3,70 mm
|
| 22. |
ZM2905705
|
[REQ] |
Tuning plate
|
3,80 mm
|
| 22. |
ZM2905706
|
[REQ] |
Tuning plate
|
3,90 mm
|
| 22. |
ZM2905707
|
[REQ] |
Tuning plate
|
4,00 mm
|
| 23. |
ZM2905700
|
[1] |
Control plate
|
|
| 4. |
VOE11702173
|
[1] |
Sealing ring
|
|
| 24. |
ZM2118650
|
[1] |
Plate
|
|
| 25. |
ZM2903335
|
[14] |
Screw
|
M5x16
|
| 26. |
ZM2905710
|
[1] |
Tilting, cpl.
|
|
| 27. |
ZM2905711
|
[1] |
Plate
|
|
| 28. |
VOE14503900
|
[8] |
Screw
|
M12x65
|
| 29. |
SA8230-29310
|
[2] |
Pin
|
B10x20
|
| 30. |
ZM2903189
|
[1] |
Pin
|
|
| 31. |
ZM2905712
|
[1] |
Piston
|
|
| 32. |
ZM2905714
|
[1] |
Screw nail
|
|
| 33. |
ZM2905713
|
[1] |
Piston
|
|
| 5. |
VOE15033174
|
[2] |
Lock screw
|
M18x1,5
|
| 34. |
ZM2905715
|
[3] |
Ring
|
25x1,5
|
| 35. |
ZM8096591
|
[1] |
Screw
|
M12x25
|
| 36. |
VOE15030547
|
[2] |
O-ring
|
5,28x1,78
|
| 37. |
ZM2256850
|
[2] |
O-ring
|
9,25x1,78
|
| 38. |
VOE11708087
|
[6] |
O-ring
|
7,65x1,78
|
| 39. |
ZM2270310
|
[1] |
Contact breaking plug
|
M6
|
| 40. |
ZM2902141
|
[2] |
Plug
|
|
| 41. |
ZM2905716
|
[1] |
Valve housing
|
|
| 42. |
ZM8096450
|
[4] |
Screw
|
M6x40
|
| 43. |
ZM2905551
|
[1] |
Compression spring
|
|
| 6. |
VOE15122590
|
[1] |
Pin
|
M12x50
|
| 44. |
ZM2905248
|
[1] |
Bushing
|
|
| 45. |
ZM2905550
|
[1] |
Compression spring
|
|
| 46. |
ZM2903857
|
[1] |
Spring disc
|
|
| 47. |
VOE15059650
|
[1] |
O-ring
|
29,87x1,78
|
| 48. |
ZM8094956
|
[1] |
Snap ring
|
16x1
|
| 49. |
ZM2291077
|
[1] |
Control sleeve
|
|
| 50. |
ZM2905247
|
[1] |
Piston
|
|
| 51. |
ZM2286654
|
[1] |
Pin
|
4m6x24
|
| 52. |
ZM8096431
|
[1] |
Screw
|
M6x30
|
| 53. |
VOE14211724
|
[1] |
Nut
|
M6
|
| 7. |
ZM2269280
|
[1] |
Screw nail
|
M12x80
|
| 54. |
ZM2161770
|
[2] |
Plug
|
M5
|
| 55. |
ZM2905552
|
[1] |
Bushing
|
|
| 56. |
ZM2905610
|
[1] |
Magnet, 24V
|
|
| 57. |
VOE15030501
|
[1] |
Socket
|
|
| 58. |
ZM2905717
|
[1] |
Valve housing
|
|
| 59. |
ZM8096801
|
[4] |
Screw
|
M10x55
|
| 60. |
VOE982735
|
[1] |
O-ring
|
32,92x3,53
|
| 61. |
ZM2286667
|
[1] |
Lock ring
|
8x0,8
|
| 62. |
ZM2903205
|
[1] |
Washer
|
|
| 63. |
ZM2905559
|
[1] |
Piston
|
|
| 8. |
VOE14211726
|
[2] |
Lock nut
|
M12
|
| 64. |
ZM2903201
|
[1] |
Washer
|
7x13x0,3
|
| 65. |
ZM2903202
|
[REQ] |
Washer
|
7x13x0,5
|
| 66. |
ZM2905564
|
[REQ] |
Washer
|
7x13x1,0
|
| 67. |
ZM2286666
|
[1] |
Spring
|
|
| 68. |
VOE15106589
|
[1] |
O-ring
|
17,12x2,62
|
| 69. |
ZM2903199
|
[1] |
Plug
|
|
| 70. |
ZM2905718
|
[1] |
Piston
|
|
| 71. |
ZM2286664
|
[2] |
Washer
|
|
| 72. |
ZM2906340
|
[2] |
Compression spring
|
|
| 73. |
VOE11702859
|
[2] |
O-ring
|
15,54x2,62
|
| 9. |
ZM2906772
|
[1] |
O-ring
|
148,82x3,53
|
| 74. |
ZM2286662
|
[2] |
Plug
|
|
| 75. |
ZM2905553
|
[1] |
Screw plug
|
M14x1,5
|
| 76. |
ZM2271600
|
[1] |
Screw
|
|
| 77. |
ZM2903197
|
[1] |
Pin
|
|
| 78. |
ZM2271590
|
[1] |
Screw
|
|
| 79. |
VOE14371049
|
[4] |
Allen Hd Screw
|
M12x40
|
| 80. |
VOE983770
|
[1] |
O-ring
|
140x3
|
