神钢零件查询(F4GE9684B J605) - ENGINE 5801385851 - 84369828 (1/13-) (10.105.02) - CONNECTING ROD (504264406) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
282 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2831298 | [6] | CONNECTING ROD | TOR- ASSY Contains Ref.1A, 1B, 2, 3 |
| 1A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 1B. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 2. | 4892708 | [1] | BUSHING,38.02mm ID x 41.01mm OD x 33.4mm L | TOR |
| 3. | 2831297 | [2] | FLANGE BOLT,Hex, M10 x 1.25 x 52mm, Cl 10.9 | TOR |
| 4. | 8093882 | [6] | BEARING SET | TOR |
| 4. | 8094960 | [6] | BEARING SET,(-0.250) | TOR |
| 4. | 8094961 | [6] | BEARING SET,(-0.500) | TOR |
