神钢零件查询(F4GE9684B J605) - ENGINE 5801385851 - 84369828 (1/13-) (10.402.01[02]) - THERMOSTAT - ENGINE COOLING SYSTEM (504083230-504320541-504033593-504198770) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
645 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899091 | [3] | SCREW,Hex Flange Cap, M8 x 1.25 x 40.00mm | BAS |
| 2. | 2853131 | [1] | HOUSING | TOR Superseded by part number: 504079269 |
| 4. | 2853133 | [1] | GASKET,51.5mm ID x 61.5mm OD x 16.5mm Thk | TOR Superseded by part number: 504078856 |
| 5A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 7. | 84325989 | [1] | SEAL | TOR |
| 8. | 4895078 | [1] | PIPE PLUG,1/2"-14 | TOR |
