神钢零件查询(F4GE9684C J600) - ENGINE 504124795 - 920019900 (1/13-) (0.12.0[01]) - CAMSHAFT - TIMING CONTROL (504125012) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
215 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899079 | [6] | SCREW,Hex Flg, M8 x 1.25 x 25 | TOR |
| 2. | 4896622 | [1] | DRIVEN GEAR | TOR |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 4. | 4897457 | [1] | SUPPORT | TOR |
| 5. | 2855612 | [1] | CAMSHAFT | TOR- ASSY Superseded by part number: |
| 5. | 2855612R | [1] | REMAN-CAMSHAFT | RACF4GE9684C J600 ENGINE 504124795 - 920019900, ASSY Superseded by part number: 504094080R |
| 5. | 2855612C | [1] | Return Number | RACReturn Number |
| 6. | 4899080 | [1] | DOWEL,M6 x 8 L | TOR |
