| 1. |
86616066
|
[6] |
BELT,177.80 mm W x 10681.00 mm L
|
NH
Laced, Chevron Superseded by part number: 87056535
|
| 1. |
87032888
|
[6] |
BELT,7.00" W x 420.50" L
|
PA
Endless, Chevron Superseded by part number: 84141595
|
| 2. |
86625980
|
[1] |
DIA KIT, HARVESTER
|
NH
Lacing Cable, Includes: (18) Cable Tubes, (8) Lacing Cables & Instructions Superseded by part number: 84399081
|
| . . |
9847138
|
[1] |
REPAIR KIT
|
NH
Lacing, Includes: Box of 18 Cards, 45 Hooks per Card
|
| 3. |
86501067
|
[2] |
SUPPORT
|
NH
|
| 4. |
838-5526
|
[12] |
LOCK PIN,M5 x 26, Slotted
|
CAS
Superseded by part number: 82848074, 130045
|
| 5. |
86628013
|
[1] |
GUIDE
|
NH
Belt
|
| 6. |
811-10030
|
[7] |
CARRIAGE BOLT,Sht Sq Nk, M10 x 1.5 x 30mm, Cl 8.8
|
CAS
Superseded by part number: 86512446
|
| 7. |
825-1410
|
[7] |
NUT,M10, Cl 8
|
CAS
Superseded by part number: 100016
|
| 8. |
9800832
|
[1] |
ROD
|
NH
Belt Guide
|
| 9. |
432-816
|
[2] |
COTTER PIN,1/8" x 1"
|
CAS
Superseded by part number: 80755
|
| 10. |
86628015
|
[1] |
ANGLE
|
NH
|
| 11. |
391510
|
[8] |
SELF-TAP SCREW,Hex Wshr Hd, M8 x 1.25 x 20mm
|
NH
Self Tapping, M8 x 20
|
| 12. |
86628012
|
[1] |
SUPPORT
|
NH
|
| 14. |
825-51410
|
[4] |
FLANGE NUT,M10, Flg Ser
|
CAS
Superseded by part number: 43435
|
| 15. |
86502852
|
[3] |
ROLLER,114.3mm OD x 1176mm L
|
NH
Tailgate Idler, 4 1/2", Includes: (2) Ref. 16 Superseded by part number: 84602592
|
| 16. |
86500662
|
[6] |
BEARING ASSY
|
NH
Includes: Ref. 18
|
| 17. |
86516322
|
[6] |
SUPPORT
|
NH
Superseded by part number: 87654792
|
| 18. |
8050825
|
[6] |
BEARING, ROLLER, CYL,38.1 mm ID x 80 mm OD x 30.163 mm
|
L
Superseded by part number: F82059
|
| 19. |
9823371
|
[4] |
SHAFT
|
NH
Includes (1) Pins Superseded by part number: 87023402
|
| . . |
29684
|
[8] |
WASHER,13.5mm ID x 50.8mm OD x 5.52mm Thk
|
NH
17/32" ID x 2" OD x 3/16" Thk
|
| . . |
614-12030
|
[8] |
BOLT,Hex, M12 x 1.75 x 30mm, Cl 8.8, Full Thd
|
IH
Superseded by part number: 9706687
|
| . . |
65319
|
[8] |
WASHER,13.1mm ID x 25.4mm OD x 3.68mm Thk
|
NH
|
| 21. |
86521602
|
[2] |
SUPPORT
|
NH
Superseded by part number: 87023400
|
| 23. |
9823372
|
[1] |
SHAFT,1135mm L
|
NH
Includes (2) Pins
|
| 24. |
9829398
|
[1] |
ROLLER
|
NH
Tailgate Nose, 5.56", Includes: Ref. 25
|
| 25. |
9848489
|
[2] |
BEARING ASSY,73 mm ID x 132.1976 mm OD x 38.10 mm, Round Bore
|
NH
Includes, Ref. 38 Bearing Superseded by part number: 47531138
|
| 26. |
86521601
|
[2] |
SUPPORT
|
NH
|
| 27. |
9614071
|
[2] |
CAP COVER
|
NH
|
| 30. |
811-8020
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, M8 x 1.25 x 20mm, Cl 8.8
|
CAS
Superseded by part number: 86507486
|
| 31. |
825-2408
|
[4] |
FLANGE NUT,M8 x 1.25, Flg, Cl 8
|
CAS
Superseded by part number: 86505868
|
| 32. |
86637096
|
[1] |
TAILGATE
|
NH
Includes: Ref. 51 - 53
|
| 33. |
86637243
|
[2] |
PLATE ASSY.
|
NH
Superseded by part number: 47798993
|
| 34. |
273127
|
[10] |
WASHER,16.67mm ID x 28.57mm OD x 7.37mm Thk
|
NH
1-1/8" OD
|
| 35. |
614-16050
|
[10] |
BOLT,Hex, M16 x 2 x 50mm, Cl 8.8, Full Thd
|
CAS
Superseded by part number: 120090
|
| 36. |
9829271
|
[2] |
SPACER
|
NH
|
| 37. |
9845575
|
[1] |
SCRAPER BLADE
|
NH
|
| 39. |
9842286
|
[1] |
ROLLER
|
NH
Tailgate Idler, 3-1/2" Superseded by part number: 84600572
|
| 40. |
86637214
|
[1] |
ROD
|
NH
|
| 41. |
9845448
|
[1] |
PIN,31.7mm OD x 83.7mm L
|
NH
|
| 42. |
86628108
|
[1] |
SPRING
|
NH
|
| 43. |
495-21044
|
[2] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 44. |
432-812
|
[1] |
COTTER PIN,3/4" OAL x 1/8" W
|
CAS
Superseded by part number: 80756
|
| 46. |
814-12050
|
[4] |
BOLT,Hex, M12 x 1.75 x 50mm, Cl 8.8
|
CAS
Superseded by part number: 9706702
|
| 49. |
432-1228
|
[2] |
COTTER PIN,3/16" x 1 3/4"
|
CAS
Superseded by part number: 87399
|
| 50. |
495-11106
|
[2] |
WASHER,1", SAE
|
CAS
Superseded by part number: 87367
|
| 51. |
86631519
|
[1] |
DANGER DECAL
|
NH
English
|
| 51. |
86632802
|
[1] |
DECAL
|
NH
DANGER, French
|
| 52. |
86547711
|
[1] |
DECAL,SMV
|
NH
SMV
|
| 53. |
86631516
|
[1] |
WARNING DECAL
|
NH
English
|
| 53. |
86632799
|
[1] |
DANGER DECAL
|
NH
WARNING, French
|
