纽荷兰零件查询(DC150PS) - CRAWLER DOZER (0.240[02]) - TURBOCHARGER - COMPONENTS New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
407 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76193277 | [1] | SEAL | MAC Superseded by part number: J937706 |
| 2. | 76192430 | [2] | IMPELLER | TOR Superseded by part number: J534309 |
| 3. | 3503100 | [2] | CAMSHAFT BEARING | L |
| 5. | 76191891 | [1] | SEAL | TOR Superseded by part number: J919369 |
| 6. | 3519302 | [1] | SCREEN | L Superseded by part number: J519302 |
| 7. | 3519336 | [1] | SHAFT | L |
| 8. | 76192410 | [1] | LOCKING RING | TOR Superseded by part number: REFERENCE |
| 9. | 3762259 | [4] | LOCKING RING | L |
| 10. | 76192412 | [1] | DEFLECTOR | TOR |
| 11. | 76192417 | [1] | O-RING | TOR |
| 12. | 76192419 | [1] | COVER PLATE | TOR |
| 13. | 76192420 | [1] | BUSHING | TOR |
| 14. | 76192423 | [1] | PLATE | TOR |
| 15. | 76192424 | [1] | HOSE CLIP | TOR |
| 16. | 76192408 | [1] | GUIDE PIN | TOR |
| 17. | 76193279 | [1] | HOUSING | TOR Superseded by part number: J532631 |
| 18. | 76192428 | [1] | LOCKING RING | TOR |
| 20. | 76193280 | [1] | RING | TOR |
| 22. | 75286733 | [1] | LOCKING RING | CMI |
| 23. | 75286722 | [1] | O-RING | CMI |
| 24. | 75286728 | [4] | SCREW | CMI8X1,25X12 |
