斗山零件查询ARM PIPING-LOCK VALVE DX420LC-5(S/N:10001~10010) Doosan parts catalog online
广数供应链运营团队, 14 02月, 2025，浏览：
263 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| -. |
420212-02521
|
[-] |
|
|
| 1. |
DS20131964
|
[2] |
|
|
| 10. |
2180-1026D23
|
[1] |
O-RING
|
|
| 11. |
DS2230004
|
[2] |
|
|
| 12. |
S2218966
|
[8] |
BOLT;SOCKET M14X2.0X65
|
|
| 13. |
2124-1084D2
|
[30] |
CLIP;BAND
|
|
| 14. |
110406-00478
|
[1] |
|
|
| 15. |
S0563466
|
[2] |
BOLT
|
|
| 16. |
K1015638
|
[2] |
WASHER;HARDENED
|
|
| 17. |
K1004006
|
[1] |
PLATE
|
|
| 18. |
S8030061
|
[2] |
O-RING
|
|
| 19. |
S8030041
|
[4] |
O-RING
|
|
| 3. |
400305-00028C
|
[1] |
|
|
| 4. |
410114-00211
|
[1] |
|
|
| 5. |
S8000111
|
[2] |
O-RING
|
|
| 6. |
DS2232019
|
[2] |
|
|
| 7. |
DS0301032
|
[2] |
NUT
|
|
| 8. |
DS2805009
|
[4] |
CLIP
|
|
| 9. |
S5110803
|
[4] |
WASHER
|
|
