纽荷兰零件查询(DC180.B) - CRAWLER DOZER TIER 2 (3/03-) (9.353[01]) - TRACK ROLLER GUARD - LT OPTIONAL CODE 784119111- VERSION (01) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
481 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76092105 | [2] | GUARD | LEC- REAR LEFT |
| 1. | 76092133 | [2] | GUARD | LEC- REAR RIGHT |
| 2. | 76071498 | [6] | SPACER | LEC |
| 3. | 76092134 | [2] | GUARD | LEC- CENTER LEFT ASSY |
| 3. | 76092135 | [2] | GUARD | LEC- CENTER RIGHT ASSY |
| 5. | 15840537 | [12] | BOLT,Hex, M16 x 1.5 x 50mm, Cl 10.9, Full Thd | LEC Superseded by part number: 15840534 |
| 6. | 79005240 | [12] | WASHER,16.8mm ID x 36mm OD x 8mm Thk | LEC16X35,5X8 |
| 7. | 11383631 | [12] | BOLT,Hex, M20 x 1.5 x 50, 10.9, Full Thd | LEC |
| 8. | 79032222 | [12] | WASHER,21mm ID x 40mm OD x 8mm Thk | LEC |
| 9. | 76093927 | [2] | GUARD | LEC- REAR LEFT |
| 9. | 76095075 | [2] | GUARD | LEC- REAR RIGHT |
| 10. | 76093928 | [4] | SPACER | LEC |
| 11. | 12644931 | [12] | WASHER,14.4mm ID x 32mm OD x 4mm Thk | LEC |
| 13. | 11112831 | [8] | SCREW,Hex, M12 x 40mm, Cl 10.9, Full Thd | LEC Superseded by part number: 11125434 |
| 14. | 11115631 | [12] | BOLT,Hex, M14 x 35, 10.9, Full Thd | LEC |
| 15. | 12648531 | [8] | WASHER,12.2mm ID x 28mm OD x 4mm Thk | LEC Superseded by part number: 86625256 |
| 16. | 11702921 | [8] | NUT,M12, Cl 10 | LEC Superseded by part number: 17038425 |
