纽荷兰零件查询(DC180.B) - CRAWLER DOZER TIER 2 (3/03-) (9.464[01]) - REAR COUNTERWEIGHT - OPTIONAL CODE 76074914 - VERSION (01-02) New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
167 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76074915 | [1] | WEIGHT | LEC |
| 2. | 76002739 | [6] | WASHER | LECIN ALTERNATIVE Superseded by part number: 79005245 |
| 2. | 79005245 | [6] | WASHER,25mm ID x 55mm OD x 9mm Thk | LEC24X55 IN ALTERNATIVE |
| 3. | 15998737 | [2] | BOLT,Hex, M24 x 2 x 180mm, Cl 10.9 | LEC |
| 4. | 13957530 | [4] | STUD | LEC24X2X157 |
| 5. | 12164521 | [4] | NUT,Hex, M24, 2mm Pitch,19mm High, Cl 10 | MOD24X2X19 Superseded by part number: 12164527 |
