Pos.	Part No	Qty	Parts name	Comments
.	31FS-03001	[1]	REACH CYL-20-7(V-MAST)	V-MAST,HBR20-7
.	31FS-03201	[1]	REACH CYL-20-7(TF-MAST)	TF-MAST,HBR20-7
.	31FS-03101	[1]	REACH CYL-25-7(V-MAST)	V-MAST,HBR25-7
.	31FS-03301	[1]	REACH CYL-25-7(TF-MAST)	TF-MAST,HBR25-7
1.	31Y3-24370	[1]	TUBE ASSY	V-MAST,HBR20-7
1.	31Y3-24390	[1]	TUBE ASSY	TF-MAST,HBR20-7
1.	31Y3-24410	[1]	TUBE ASSY	V-MAST,HBR25-7
1.	31Y3-24430	[1]	TUBE ASSY	TF-MAST,HBR25-7
2.	31Y3-24380	[1]	ROD ASSY	V-MAST,HBR20-7
2.	31Y3-24400	[1]	ROD ASSY	TF-MAST,HBR20-7
2.	31Y3-24420	[1]	ROD ASSY	V-MAST,HBR25-7
2.	31Y3-24440	[1]	ROD ASSY	TF-MAST,HBR25-7
3.	31Y3-24290	[1]	GLAND
4.	S731-028020	[1]	DU BUSH
K5.	Y200-028011	[1]	SEAL-ROD
K6.	Y120-028011	[1]	WIPER-DUST
K7.	S631-044004	[1]	O-RING
K8.	S632-050004	[1]	O-RING
9.	31Y3-24300	[1]	PISTON
K10.	Y430-050022	[1]	SEAL-PISTON
K11.	S631-014004	[1]	O-RING
12.	31YC-65120	[1]	NUT-NYLON
13.	S621-014001	[2]	O-RING,ORFS
K.	31Y3-24320	[1]	SEAL KIT	SEE ILLUST
