纽荷兰零件查询(DC180.B) - CRAWLER DOZER TIER 2 (3/03-) (9.653[02]) - ROPS CAB WITH CONDITIONER - OPTIONAL CODE 784110121 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
227 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79096265 | [1] | TANK | LEC- WASHER -5 L; Cap Not Serviced Separately |
| 2. | 76004366 | [1] | SECURING STRAP | LEC |
| 3. | 76066333 | [1] | ELBOW | LEC |
| 4. | 76066174 | [2] | SHUT-OFF VALVE | LEC |
| 5. | 76092257 | [1] | FLEXIBLE HOSE | LEC |
| 6. | 76092256 | [1] | FLEXIBLE HOSE | LEC |
| 7. | 79083842 | [4] | HOSE CLAMP,M16-27 | LEC Superseded by part number: 18088392 |
| 8. | 79013422 | [2] | CABLE TIE,145mm L | LEC |
| 9. | 79095451 | [2] | NOZZLE | LEC |
| 10. | 79097787 | [1] | TEE | LEC |
| 11. | 79095816 | [1] | HOSE | LEC Superseded by part number: 19044986 |
| 12. | 76068436 | [1] | HOSE,4.00 mm ID x 700.00 mm | LEC Superseded by part number: 19044986 |
| 13. | 76068437 | [1] | HOSE,4.00 mm ID x 3000.00 mm | LEC Superseded by part number: 19044986 |
| 15. | 10450190 | [2] | CLAMP,10mm, Coat, 9mm Bolt Hole, P Type | JES66X9 Superseded by part number: |
| 16. | 79011405 | [1] | CLAMP | LEC Superseded by part number: 86637995 |
| 17. | 15970331 | [1] | BOLT,Hex, M10 x 1.25 x 16mm, Cl 10.9, Full Thd | LEC Superseded by part number: 15970324 |
