神钢零件查询(F4GE9684D J604) - ENGINE 5801385853 - 84369830 (1/07-12/11) (10.101.01) - CYLINDER HEAD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
707 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4892861 | [6] | CAPTIVE WASHER SCREW,Wash Hd, M12 x 1.75 x 73 | TOR |
| 1. | 4892859 | [14] | BOLT,Flng, M12 x 1.75 x 143mm | TOR |
| 3. | 4895183 | [24] | COLLET | TOR |
| 4. | 4895188 | [6] | STD EXHAUST VALVE | TORSTD ENGINE EXHAUST VALVE Exhaust |
| 5. | 4895187 | [6] | STD INLET VALVE | TORSTD ENGINE INLET VALVE Intake |
| 6. | 4895347 | [12] | SEAL | TOR |
| 7. | 2831472 | [12] | VALVE SPRING,Compression, 32.8mm OD x 65.7mm L | TOR Superseded by part number: 4895215 |
| 8. | 4895184 | [12] | RETAINER,34mm OD, 10.63mm ID, 14.5mm L | TOR |
| 9. | 4895765 | [1] | CYLINDER HEAD | TORAssy, Contains Ref. 9A - 12 |
| 9A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 10. | 4895179 | [3] | EXPANSION PLUG,M20.93 | TOR |
| 11. | 4897179 | [6] | VALVE SEAT,38 mmID x 47mm OD x 6.9mm L | TORIntake |
| 12. | 4897178 | [6] | VALVE SEAT,36mm ID x 43mm OD x 6.7mm L | TORExhaust |
| 13. | 4895078 | [3] | PIPE PLUG,1/2"-14 | TOR |
| 14. | 2830922 | [1] | CYLINDER HEAD GASKET,1.4mm Thk | TOR1,25mm Thk |
| 14. | 2830923 | [1] | CYLINDER HEAD GASKET,1.15mm Thk | TOR1,15mm Thk |
