凯斯零件查询(RBX462) - CASE IH ROUND BALER (1/03-7/05) (18.49[01]) - KIT 4 FT SERPENTINE SCRAPPER Case Agriculture
广数供应链运营团队, 14 02月, 2025，浏览：
783 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
87347783
|
[1] |
DIA KIT, HARVESTER
|
PA
Incl 2 - 8
|
| 2. |
84399335
|
[1] |
INSTRUCTION
|
NH
|
| 3. |
43138
|
[8] |
BOLT,Hex, M10 x 1.5 x 20mm, Cl 8.8
|
NH
|
| 4. |
140045
|
[8] |
BELLEVILLE WASHER,M10 Bolt Size x 22mm OD x 1.6mm Thk
|
NH
|
| 5. |
9845575
|
[2] |
SCRAPER BLADE
|
NH
|
| 6. |
9804258
|
[16] |
BOLT,Hex, M8 x 1.25 x 20mm, Cl 8.8
|
NH
|
| 7. |
86637019
|
[2] |
SUPPORT
|
NH
|
| 8. |
87010760
|
[2] |
ANGLE
|
PA
|
