纽荷兰零件查询(DC180.B) - CRAWLER DOZER TIER 2 (3/03-) (9.653[26]) - ROPS CAB - COMPONENTS - OPTIONAL CODE 784110121 New Holland Constructuion
广数供应链运营团队, 14 02月, 2025，浏览：
440 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76045521 | [2] | CEILING LAMP | LEC Superseded by part number: 76048462, 5141635, 76048463 |
| 2. | 76048462 | [2] | BULB | LEC5W-24V |
| 3. | 10863190 | [2] | BULB,C5W, 24V, 5W | MKT5W-24V |
| 4. | 76045522 | [2] | BRACKET | LEC |
| 5. | 13272811 | [4] | SCREW,Pozidriv Pan Hd, M4 x 30mm, Cl 5.8 | LEC Superseded by part number: 86511825 |
| 6. | 13271911 | [2] | SCREW,Pozidriv Pan Hd, M4 x 10mm, Cl 5.8, Full Thd | LEC Superseded by part number: 13271914 |
| 7. | 14496201 | [6] | WASHER,M4 x 9 | BAS Superseded by part number: 14496204 |
| 8. | 76067263 | [2] | PIN | LEC |
| 9. | 76067264 | [2] | PLATE | LEC |
| 10. | 14496701 | [4] | WASHER,13.00mm ID x 24.00mm OD x 2.50mm, CST, ZND | TTF Superseded by part number: 14496704 |
| 11. | 76043511 | [2] | PIN | LEC Superseded by part number: 1482300 |
| 12. | 76067753 | [2] | PLATE | LEC |
| 13. | 76067754 | [2] | LATCH | LEC |
| 14. | 10902424 | [8] | SCREW,Hex, M6 x 20mm, Cl 8.8, Full Thd | TTF Superseded by part number: |
| 15. | 10523404 | [16] | WASHER,6.15mm ID x 18mm OD x 2mm Thk | BAS Superseded by part number: 10523401 |
| 16. | 15896211 | [8] | NUT,M6, Cl 8 | JES Superseded by part number: 17037821 |
| 17. | 154227179 | [2] | GUARD | LEC Superseded by part number: 4227179 |
| 18. | 9471086 | [2] | BUTTON | LEC- HANDLE |
| 19. | 71487113 | [2] | SHIELD | LEC |
| 20. | 76067658 | [2] | SPACER | LEC |
| 21. | 71488179 | [2] | RING NUT | LEC |
| 22. | 76067265 | [2] | FLEXIBLE CONTROL | LEC |
| 23. | 76080697 | [2] | TRIP ARM | LEC |
| 24. | 76067756 | [2] | PIN | LEC |
| 25. | 11087671 | [4] | CIRCLIP,M5 | BAS Superseded by part number: 86632599 |
| 26. | 76048976 | [2] | ELASTIC STOP | LEC- LOWER |
| 27. | 14496634 | [2] | WASHER,M10 | BURx 21 Superseded by part number: 14496621 |
| 28. | 11701714 | [2] | NUT | LEC10 Superseded by part number: 17038131 |
| 30. | 76048389 | [2] | PLATE | LEC |
| 31. | 76079011 | [2] | BUMPER | LEC |
