神钢零件查询(F4GE9684D J604) - ENGINE 5801385853 - 84369830 (1/07-12/11) (10.218.01 01) - PIPING - FUEL Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
404 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1A. | NSS | [1] | NOT SOLD SEPARAT | CON |
| 2A. | NSS | [1] | NOT SOLD SEPARAT | CONASSY Contains Ref.2A, 3 |
| 3. | 4894095 | [2] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 9. | 16586224 | [1] | SCREW,Hex Flg, M8 x 1.25 x 16mm, Cl 8.8 | TOR Superseded by part number: 16586225 |
| 10. | 2852111 | [1] | CLIP | TOR Superseded by part number: 504065285 |
| 11. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
