神钢零件查询(F4GE9684D J604) - ENGINE 5801385853 - 84369830 (1/07-12/11) (10.254.01) - INTAKE MANIFOLD Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
572 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2856513 | [1] | COVER | TOR |
| 2. | 4899039 | [10] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TOR |
| 3. | 2830891 | [1] | AIR INTAKE TUBE | TOR |
| 5. | 4893036 | [1] | PIPE PLUG,3/4"-14 NPTF | TORAlternate with 2854866 Superseded by part number: 2854866 |
| 5. | 2854866 | [1] | HEX SOCKET PLUG,3/4"-14 NPTF | TORAlternate with 4893036 Superseded by part number: 4893036 |
| 6. | 4899921 | [1] | GASKET,1.2mm Thk | TOR |
