神钢零件查询(F4GE9684E J615) - ENGINE 5801763602 - 47613194 (8/14-) (10.101.AA) - CYLINDER HEAD & RELATED PARTS, Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
957 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4892861 | [6] | CAPTIVE WASHER SCREW,Wash Hd, M12 x 1.75 x 73 | TOR |
| 2. | 4892859 | [14] | BOLT,Flng, M12 x 1.75 x 143mm | TOR |
| 3. | 2830922 | [1] | CYLINDER HEAD GASKET,1.4mm Thk | TOR1.25MM |
| 3. | 2830923 | [1] | CYLINDER HEAD GASKET,1.15mm Thk | TOR1.15MM |
| 4. | 4895183 | [24] | COLLET | TOR |
| 5. | 4895085 | [1] | EXPANSION PLUG,25.74mm | TOR |
| 6. | 4895184 | [12] | RETAINER,34mm OD, 10.63mm ID, 14.5mm L | TOR |
| 10. | 4895347 | [12] | SEAL | TOR |
| 11. | NS | [1] | NOT SERVICED | BAS |
| 12. | 4895179 | [3] | EXPANSION PLUG,M20.93 | TOR |
| 13. | 4897178 | [6] | VALVE SEAT,36mm ID x 43mm OD x 6.7mm L | TOR |
| 14. | 4897179 | [6] | VALVE SEAT,38 mmID x 47mm OD x 6.9mm L | TOR |
| 16. | 4895085 | [1] | EXPANSION PLUG,25.74mm | TOR |
