神钢零件查询(F4GE9684F J602) - ENGINE - 504375333 - 84250815 (1/13-) (10.254.01) - INTAKE MANIFOLD (2852332 - 2855097 - 2853370) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
721 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4895294 | [4] | BOLT,Flng, M8 x 1.25 x 80mm, Cl 10.9 | TOR |
| 2. | 4895424 | [1] | INLET MANIFOLD | TOR |
| 3. | 4893036 | [2] | PIPE PLUG,3/4"-14 NPTF | TOR Superseded by part number: 2854866 |
| 4. | 4899921 | [2] | GASKET,1.2mm Thk | TOR |
| 5. | 2831019 | [1] | HEATER,24V | TOR |
| 6. | 4899039 | [10] | BOLT,Flng, M8 x 1.25 x 25mm, Cl 10.9 | TOR |
| 7. | 2856513 | [1] | COVER | TOR |
