神钢零件查询(F4GE9684F J602) - ENGINE - 504375333 - 84250815 (1/13-) (10.402.03) - WATER PUMP DRIVE (2853448) Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
419 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2853208 | [1] | BELT,1660.00 mm L, 8 Ribs | CAS Superseded by part number: 504079075 |
| 2. | 2852398 | [1] | IDLER WHEEL,65mm OD | TOR Superseded by part number: 504065877 |
| 3. | 2856946 | [1] | BELT TENSIONER | TOR Superseded by part number: |
| 4. | 2852397 | [1] | IDLER,65mm OD | TOR Superseded by part number: 504065878 |
| 5. | 2852245 | [1] | PULLEY,65mm OD | TOR Superseded by part number: 504065879 |
