神钢零件查询(F4GE9684G J601) - ENGINE - 504375341 - 84250441 (7/13-) (10.106.AA) - CAMSHAFT Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
789 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899079 | [6] | SCREW,Hex Flg, M8 x 1.25 x 25 | TORM8 x 1.25 x 25 |
| 2. | 4896622 | [1] | DRIVEN GEAR | TOR |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BASM8 x 1.25 x 16 |
| 4. | 4897457 | [1] | SUPPORT | TOR |
| 5. | 2855612 | [1] | CAMSHAFT | TORASSY, Incl 6, 7 Superseded by part number: |
| 5. | 2855612R | [1] | REMAN-CAMSHAFT | RACF4GE9684E J610 ENGINE - 5801590403 - YN02P00117F1, ASSY Superseded by part number: 504094080R |
| 5. | 2855612C | [1] | Return Number | RACReturn Number |
| 6. | 4899080 | [1] | DOWEL,M6 x 8 L | TOR |
| 7. | 2855612R | [1] | REMAN-CAMSHAFT | RACF4GE9684E J610 ENGINE - 5801590403 - YN02P00117F1, Reman for New PN 2855613 Superseded by part number: 504094080R |
| 7. | 2855612C | [1] | Return Number | RACReturn Number |
