神钢零件查询(F4GE9684G J601) - ENGINE - 504375341 - 84250441 (7/13-) (10.210.AF) - FUEL LINE Kobelco
广数供应链运营团队, 14 02月, 2025，浏览：
995 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2853322 | [1] | PIPE | TORASSY, Incl 2, 3 Superseded by part number: 504072176 |
| 2. | 4894095 | [2] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TORID = 8.0 x 2.5 |
| 3. | NSS | [2] | NOT SOLD SEPARAT | CONPipe, Incl in 1 |
| 4. | 2853325 | [1] | PIPE | TORASSY, Incl 2, 5 Superseded by part number: 504072177 |
| 5. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 4 |
| 6. | 2852111 | [2] | CLIP | TOR Superseded by part number: 504065285 |
